DPN/C - Enclosed belt dosing system

The DPN-C series dosing system are recommended for dosing powdery materials with medium-low flow rates.
The machines consist of a storage hopper, a feed device and a scale that controls the loss in weight during product discharge.
For every type of dosing system there isa wide range of motor drives and customisations suited to the process.
The enclosure ensures that only the minimum amount of powders are dispersed into the environment.
When the scale is combined with the suitable electronic control unit, the machine can operate in loss-in-weight batching mode and/or continuous mode with controlled flow rate (in the latter, hopper refill is controlled by the electronic control unit with no need to interrupt the batching process).


gravimetric dosing with belt
TECHNICAL CHARACTERISTICS VALUE
STAD reserves the right to modify product characteristics without prior notice.
Load bearing frame Carbon steel
Product inlet valve Stainless steel
Filling and discharge hoppers Stainless steel
Belt With calibrated jointing in various materials according to application
Sides In steel and soft strips according to application
Windows Polycarbonate and removable
Optional three-phase multi-voltage or semi-vector asynchronous motor
Belt cleaning system Belt scraper
Weighing system C3 IP67 triple load cell
Junction boxes Available for load cell junction
Servo-ventilation Optional according to application
ATEX conformity Available as an option for ATEX 22 zones
